Thicknesser
Model DGI-63D
Replacement Parts
FIG. CODE QTY. NAME FIG.
CODE QTY. NAME
211… 89DS-K116-0 01… Gear with pins and bushing
246… 07-01-0038-0 01… Spring 84DS-K157-0
212… 06-02-0076-0 01… Allen screw without head 247… 26-03-0008-0 01… Pin extension Ø8x60
213… 8NCV-K263-0 01… Key 248… 24-04-0002-0 01… Galvanized gas plug ½”
214… 88DS-KK86-0 01… Transmission pin 249… 06-20-0019-0 01… Rubber ring nº 2232
215… 89DS-KK34-0 01… Engaging shaft 250… 03-00-0008-0 01… Bearing 6008-2RZ
216… 89DS-K115-0 01… Gear with pins and bushing 251… 84DS-KK79-0 01… Reducer gear 6
th
217… 06-03-0065-0 03… Allen screw with head M8x1,25x25 252… 84DS-K114-0 01… Stop washer
218… 06-13-0033-0 03… Lock washer Ø8,4x2 253… 03-00-0007-0 01… Bearing 6007-2RS
219… 07-01-0015-0 01… Spring 8NMO-KK93-0 254… 06-20-0018-0 01… Rubber ring nº2230
220… 16-26-0006-0 01… Steel ball Ø3/16” 255… 06-20-0017-0 02…
Rubber ring nº2225
221… 89DS-K110-0 01… Counpling 256… 03-00-0028-0 02… Bearing 6204
222… 88DS-K100-0 01… Lever support 257… 84DS-KK78-0 01… 4
th
Reducer gear
223… 06-09-0021-0 01… Hex nut M10x1,5 258… 84DS-KK77-0 01… Reducer gear 3
rd
and 5
th
224… 88DS-K103-0 01… Lever 259… 8NCV-K243-0 01… Key
225… 27-00-0007-0 01… Bakelite handle 8NCA-KK17-0 260… 84DS-KK76-0 01… 2
nd
Reducer gear
226… 89DS-KK50-0 01… Coupling lever 261… 84DS-KK75-0 01… 1
st
Reducer gear
227… 89DS-KK48-0 01… Gear support 262… 8NCV-K315-0 01… Key
228… 06-04-0119-0 01… Hex head screw M8x1,25x25 263… 04-00-0010-0 01… Retainer sabo 00266-BR1
229… 88DS-KK83-0 01… Gear with 20 teeth 264… 03-00-0081-0 01… Bearing 6204-2RS
230… 8NCV-K262-0 01… Key 265… 06-03-0072-0 01… Allen screw with head M6x1x30
231… 88DS-KK76-0 01… Intemediate shaft 266… 84DS-KKK6-0 01… Reducer front box
232… 8NCV-K329-0 01… Key
267… 84DS-KK49-0 01… Reducer washer
233… 88DS-KK80-0 01… Gear with 22 teeth 268… 06-06-0034-0 01… Flat head screw M8x1,25x25
234… 8NCV-K244-0 01… Key 269… 24-08-0001-0 01… Oil level sight glass ½”
235… 89DS-KK33-0 01… Handwheel shaft 270… 84DS-K103-0 01… Reducer washer
236… 89DS-KK36-0 01… Gear 271… 06-06-0026-0 01…
Flat head screw M8x1,25x20
237… 06-18-0005-0 01… Spring ring E-16 272… 8NPM-K103-0 01… Reducer driven pulley (for 60 Hz)
238… 11-33-0003-0 01… Terminal box 273… 8NPM-K107-0 01… Reducer driven pulley (for 50 Hz)
239… 11-03-0015-0 01… Cable clamp 274… 06-03-0075-0 04… Allen screw with head M6x1x50
240… 11-02-0048-0 01… Terminal 8NAE-K042-0 275… 06-03-0074-0 01… Allen screw with head M6x1x40
241… 06-09-0026-0 02… Hex nut M5x0,8 276… 16-17-0010-0 01… Reducer joint 84DS-KK97-0
242… 06-05-0037-0 02… Round head screw M5x0,8x12 277… 84DS-KK47-0 01… Screw tilter nut
243… 84DS-KKK7-0 01… Reducer gear box 278… 06-09-0001-0 01… Hex nut M16x2
244… 26-03-0004-0 01… Extension pin Ø8x40 279… 06-18-0034-0 01… Spring ring RS-9
245… 84DS-K165-0 01… Reducer pin 280… 84DS-K158-0 01… Belt stretcher
29
