GD200A series VFD Basic operation instruction

-100-

Start

Power on after right wiring

Restore to the factory

parameters (P00.18=1)

G/P selection(P00.17)

P02.01~P02.05

Press QUICK/JOG to jog

If the rotation direction is

wrong, power off to change

the wires and repower on

Autotuning mode

P00.15=1 P00.15=3

Press RUN to autotune

and then stop

Set running frequency

Set ( P00.01,P00.02)

P00.15=2

P00.00

P00.00=1 P00.00=2

Set P03 Set P04

Set P01

Run

Stop

End

Set

Note: If fault occurs, please do as the "Fault Tracking". Estimate the fault reason and settle the

issue.

INVT GD200A-2R2G-4 User Manual
