Iomega ZipCD 650 - Connect IDE Data and Audio Cables

6
M
A
ST
E
R
S
L
A
V
E
C
A
B
L
E
S
E
L
E
C
T
AUDIO OUT
R
G
N
D
L
C
S
M
S
L
A
I
D
E
P
IN
1
DC INPUT
+
5
G
N
D
+
1
2
ZipCD
PIN 1
Pin 1
40 Pin
Pin 1
Connect the ZipCD
™
drive to the computer’s IDE connection
using an IDE data cable.
NOTE: You can use either the cable included with the drive or an IDE cable
that may already be connected to the computer’s motherboard.
CAUTION! Make sure PIN 1 on the cable connects to PIN 1 on the ZipCD
™
drive, the motherboard, and any other connected device.
