Connection Diagram
Items not listed under the Box Contents are sold separately.
Features
1. Microphone Input
with Volume Control
(1/4"): This mono input
accepts a 1/4" input
such as a microphone,
guitar, or other musical
instrument.
2. Auxiliary Input: This
stereo 3.5mm (1/8”)
input can be used to
connect a CD player,
MP3 player, or other
audio source.
3. Speaker Link:
Connect two or more
Block Rocker Max
speakers together
using a 1/8” (3.5 mm)
stereo aux cable from
the Link Output of one
Block Rocker Max to
the Aux Input of the
second Block Rocker Max. A 2’ cable is included but a longer cable can be purchased from a local electronics retailer.
4. Bluetooth Button: Press this button to enter pairing mode. To stop pairing to a Bluetooth device, press and hold this
button for 3 seconds.
5. Light Mode: Press and release this Light Mode button to toggle through these different light bar options:
• Solid White Light: The lights will be lit in a solid white color.
• Color Cycle: The lights slowly glow and cycle through colors.
• Beat Sync: The lights react to the beat of the music.
• OFF: The lights are turned off.
6. Bluetooth Icon: The Bluetooth icon will not be lit when Block Rocker Max is first powered on (unless it was previously
paired with a device). The Bluetooth icon will be lit solid when a device is paired to Block Rocker Max.
7. Master Volume Control: This adjusts the speaker’s main mix volume, which includes the Microphone Input, Auxiliary
Input, Radio Tuner, and the audio of a paired Bluetooth device.
REAR PANEL
POWER
(for charging)
TOP PANEL
MICROPHONE
MP3
PLAYER
TABLET
LINKING TWO
BLOCK ROCKER
MA
