ION Pathfinder Service Manual

19020014 fuse 522,1A/250V,Φ5*20mm 1
20080054 rear housing DN-PC8047,PP+30%,UL94V-2, 1
20080056 rear housing
DN-PC8049,rear cover,PP+30%,UL94V-2,Pantone
8403C,V1.0
1
20090041 plastic cover DN-PC0037,AC,UL94V-0,60°,MT-11010,V1.0 1
20630138 trundle IPA79S,PVC,ROHS,V1.0 2
30060227 foam 12*1000*2.0mm 0.6
30060479 foam EVA1030, 1
30090002 bunch 2.5*80mm 4
30150155 trolley IPA79S,ROHS,V1.0 1
40010038 power socket AN-J0138,DB-14-F,3P 1
70010074 the whole screw AN-C10074,M3*7mm 2
70010136 the whole screw Φ3*12mm 4
ER000630
RoHS:IPA79S packing spare
parts
IPA79S packing ASSY 1
10250280 bracket DN-MB5162,(2),SPCC,T=1.2mm 2
10410182 grill DN-ME5137,SPCC,Φ3*4P,T=1mm 1
10520185 wire 265*15mm,T=0.3mm,V1.1 1
10520220 gasket SPCC,T=0.5mm 8
16040929 plug wire AN-W4489,2P,18#,UL1015,L=450mm 1
16040961 plug wire AN-W4521,1P,18#,UL1015,750mm 1
16040962 plug wire AN-W4522,18#,UL1015,750mm 1
16041047 plug wire AN-W4608,22#,UL1617,200mm, 1
16120137 plug wire AN-WE137,1P,UL1007,18#,200mm 1
16141108 electronic wire 1P,22#,UL1007,L=150mm 1
16141109 electronic wire 1P,22#,UL1007,L=150mm 1
16150041 3.5 plug wire AN-W1540,UL2547,26#,610mm 1
17050074 electrolytic capacitor 6.8uF/50V,±10%,-40/+85℃,Φ6*17mm 1
20290074 bracket DN-PB0071,(1),ABS,blk,UL94HB,ROHS,V1.0 1
20300118 foot pad IPA79S,60°,V1.0 2
22011058 manual ION,safety manual,V15.1 1
22011059 manual IPA79S,english manual,V1.0 1
22050006 Desiccation DMT,SGS 1
23010533 packing bag （290+390）*750*0.1mm 1
23010562 packing bag PE,120*280*0.06mm 1
23010563 packing bag PE,160*260*0.025mm 1
23010606 packing bag PVC+PE+velcro,V1.0 1
23020286 polyron IPA79S,EPS,520*345*90mm,V1.0 1
23020287 polyron IPA79S,EPS,520*345*90mm,V1.0 1
23031425 cartonn IPA79S,A=A,T=6mm,546*371*557mm,V1.0 1
23090647 gift box 350+B3+A3,T=6mm532*357*537mm,V1.0 1
23100092 internal box 250g+CE,270*65*60mm.V1.0 1
24100054 magnet ring V180177T 4
30060095 foam 10*1000*1mm,EVA1030 2.7
30060452 foam 50*270*5mm,V1.0 4
30080005 velcro velcro-1,PE+velcro,blk,ROHS,V1.0 2
30080006 velcro velcro-2,PE+velcro,blk,ROHS,V1.0 1
30090002 bunch 2.5*80mm,blk 3

ION Pathfinder Specifications

General

Brand	ION
Model	Pathfinder
Category	Speakers
Language	English
