ION Pathfinder Service Manual

Component NO. Component Name Specification Qty
DR001764 RoHS:IPA79S front housing assy IPA79S front housing ASSY 1
10520221 docorative sheet aluminium alloy 2
10530032 iron prop DN-MB6032,M3 thread,10.75m 1
10530036 iron prop DN-MB6036,M3 tread hole,L=12mm 7
16041016 plug wire AN-W4577,16#,UL1015,100mm 1
16050255 shielded wire AN-W5252,UL1533/26#,UL1007/#22,100mm 1
20050046 front housing DN-PC5027,PP+30%,UL94V-2, 1
20070029 side panel DN-PC7023,PP+30%,UL94HB,PANTONE 8403C,,V1.0 2
20090039 plastic cover DN-PC0035 1
20090040 plastic cover DN-PC0036 1
20110145 lens DN-PL1114, 1
20160028 plastic air pipe DN-PT2023,ABS,80%,UL94V-2, BLK,V1.0 1
20210167 knob DN-PN2126,ABS,80%,UL94HB,PANTONE 8403C 2
20320031 handle
DN-PE2031,(2),PP+30%,UL94HB,PANTONE
8403C,V1.0
2
20320032 handle DN-PE2032,(1),PP+30%,BLK,UL94HB,1.0 2
20630140 top panel IPA79S,PP+30%,UL94HB,PANTONE 8403C,V1.0 1
20670036 button DN-PC67029 1
30060227 foam 12*1000*2.0mm, 0.8
30060483 foam EVA1030,BLK,380*2mm,V1.0 1
30090002 bunch 2.5*80mm,Black 4
30110004 gasket IPA76C,T=1mm,Φ3.5*Φ12mm,ROHS.V1.0 2
54110038 lens DN-PL1115 1
54110039 lens DN-PL1113,(2),PC,877C/199C,V1.0 1
54290018 PC sheet IPA79S,(left),PC,blk,T=0.5mm,877C,V1.0 1
54290019 PC sheet IPA79S,(right),PC,blk,T=0.5mm,877C,V1.0 1
60100024 antenna 2.4G,2DBi,ROHS 1
60100025 antenna IPA79S,AM,AM-D8x100-490uH-M7-150mm 1
60190181 FM wireless 22#,UL1007,BLK,L=1000mm, 1
70010048 the whole screw AN-C10048,M3*6mm 8
70010079 the whole screw M3*8mm 8
70010088 the whole screw Φ3*8mm 4
70010236 the whole screw Φ4*16mm 3
70010881 the whole screw M5*35mm 8
70010882 the whole screw Φ3*8mm 12
70010885 the whole screw Φ4*8mm 10
70010888 the whole screw Φ3*7mm 2
CR010983 RoHS:IPA76C2 AMP IPA76C2 AMP ASSY 1
CR011040 RoHS:IPA79S MAIN IPA79S MAIN ASSY 1
60210028 module NFC module,WN-6088 1
CR011042 RoHS:IPA79S LED IPA79S LED ASSY 1
DR001767 RoHS:IPA79S rear housing assy IPA79S rear housing ASSY 1
13110030 switch power WJ68W-165410,100-240VAC,16V/4.1A 1
16041046 plug wire AN-W4607,2P,20#,UL1007,450mm 1
16060117 ground wire AN-W715,18#,UL1015,200mm 1
16141107 electronic wire 22#,UL1007,L=1000mm 1
