IOtech DaqBook/2000 Series - 11 Specifications

DaqBook/2000 and DaqOEM/2000 Series 899595 Specifications 11-1
Specifications 11
DaqBook/2020, /2001, /2005, DaqOEM/2001, and DaqOEM/2005
General
Supply Voltage Range: 10 to 30 VDC
Power Required: 15W, assuming no DBK options
Power Available for External Signal Conditioning & Expansion Options: 5V at 1A, ±15V at 500 mA, each not to
exceed 7W on DaqBook/2020; not to exceed 10W on DaqBook/2001, /2005, DaqOEM/2001, or DaqOEM/2005
Operating Temperature: -30°C to + 70°C
Storage Temperature: -40°C to +80°C (-40° to 158°F)
Relative Humidity: 0 to 95% non-condensing
Vibration: MIL STD 810E, Categories 1 and 10
Signal I/O Connectors
DaqBook/2001 and /2005: DB37 male connectors: P1, P2, and P3
DaqBook/2020: DB37 male connectors: P1 and P2, BNC connectors, mini-Thermocouple Connectors
DaqOEM/2001 and /2005: 40-pin headers designated as JP1, JP2, and JP3. AMP # 2-103328-0
Dimensions
DaqBook/2001 and /2005: 285 mm W x 220 mm D x 45 mm H (11” x 8.5” x 1.75”)
DaqBook/2020: 285 mm W x 220 mm D x 90 mm H (11” x 8.5” x 3.5”)
DaqOEM/2001 and /2005: 27.5 cm W x 20.5 cm D
Weight
DaqBook/2001 and /2005: 1.36 kg (3 lbs)
DaqBook/2020: 2.5 kg (5.5 lbs.)
DaqOEM/2001 and /2005: 0.48 kg (1.06 lbs)
A/D Specifications
Type: Successive approximation
Resolution: 16 bit
Conversion Time: 5 µs
Maximum Sample Rate: 200 kHz
Nonlinearity (Integral): ±1 LSB
Nonlinearity (Differential): ± 2 LSB
Missing Codes: None, over full operating temperature range
Analog Inputs
Channels:
DaqBook/2001, 2005; via P1 (DB37): 16 single-ended or 8 differential, programmable on a per-channel basis as
single-ended or differential and as unipolar or bipolar.
DaqOEM/2001, /2005; via JP1 (40-pin header): 16 single-ended or 8 differential, programmable on a per-
channel basis as single-ended or differential and as unipolar or bipolar.
DaqBook/2020; via BNC connectors: 16 differential inputs. via P1 (DB37): 14 single-ended.
Expansion: Up to 256 channels, without degradation, in maximum channel-to-channel scan rate
(5 or 10 µs per channel).
Total Harmonic Distortion: -84 dB (typ)
Signal to Noise and Distortion: 80 dB (typ)
Noise: 2 LSBRMS (typ)
Bandwidth: 500 kHz
