4/40
I. Preface
This is a 2M-Pixel CMOS IP camera with the web server built in. User can view
real-time video via IE browser. It supports H.264, JPEG and MPEG4(3GPP Only)
video compression which provides smooth and high video quality. The video can
be stored in the SD card and playback remotely.
With user friendly interface, it is an easy-to-use IP camera which is designed for
security application.
II. Product Specifications
z Support video out
z High Definition 30FPS support(720P)
z IP66
z 2M-Pixel CMOS Sensor
z Power over Ethernet available
z IR LED Built in 20M available
z Mechanism IR Cut Filter Available
z H.264/ MJPEG/ MPEG4 (3GPP Only) Compression Format
z SD Card backup
z 2-way audio
z Support Cell phone/PDA/3GPP
z SDK for Software Integration
z Free Bundle 36 Channel Recording Software
Specifications
Hardware
CPU ARM 9 ,32 bit RISC
RAM 256MB
Flash 16MB
Image Sensor 1/3” CMOS(2M-Pixel)
Support DC IRIS Yes
Lens Type Vari-focal 3.6~16mm Lens
ICR Mechanism IR cut Filter
