STATUS LIGHTS
(Yellow
ECU
Detected)
Blinking Determining if ECU is present.
Steady
ECU detected, dynamic load is
active.
Not illuminated
No ECU detected. Static load is
available.
(RED)
Power
Steady
E. Brake Circuit has power and
continuity.
Not illuminated No power or continuity detected
Intermittent blink
Indicates search signal from vehi-
cle. This is typical and expected
from vehicles with an established
ECU connection.
ECU and
Power
Light
Blinking
Fault in wiring—check connections
and trouble codes.
(Blue)
Gain 1-10
Illuminated
Indicates gain from truck. 1.0-1.5V
increments.
Reverse
Lights
No power indication when
energized
Check for wiring, fuse or
connection faults.
Intermittent or erratic illumination
(RED)
Power
No power indication when
energized
Check for wiring, fuse or
connection faults.
Intermittent or erratic output
Trailer Not
Detected
Vehicle does not recognize the
Brake Force Meter as a trailer
Check Set-up Procedure.
For 2016 and 2017 Ford models
- follow Alternative Set-up
Procedure (Below).
If you suspect your vehicle is not
compatible with this tool, contact
IPA
®
at tech247@ipatools.com
or 845-679-4500 for available
updates.
7
CONTINUED CHART
To Next Page
