CT40 TECHNICAL SPECIFICATIONS
CT40
BT50
Cleaned track width mm 495
Squeegee width mm 816
Hourly performance m2/h 2250
Number of brushes n° 1
Brush diameter mm 495
Max brush pressare gr/cm² 11.54
Brush rotation speed g/1¹ 155
Brush motor power W 550
Drive control / Electronic
Drive motor rated power W 120
Maximum speed Km/h 3.5
Suction motor power W 480
Solution tank L 40
Recovery tank l 45
Wheel diameter mm 200
Gross weight Kg 202
Transported weight Kg 126
Number of batteries n° 2
Series battery voltage V 24
Single battery capacity
Ah(5h)
Ah(20)
110
140
Single battery weight Kg 36
Power supply cable length mm /
Power supply voltage V /
Power supply frequency Hz /
Battery compartment size (length. width. height) mm 345 x 170 x 300
Machine size (length. width. height)
mm
X/Y/Z
1230 x 520 x 960
Dimensions of packing (length. width. height) mm 1270 x 680 x 1227
Sound Pressure
LpA
[dB]
74
(measurement uncertainty) k
K
[dB]
3.2
Hand vibration
HAV
[m/sec2]
0.9
(measurement uncertainty) k [m/sec2] 0.5
Table A Data can be changed without notice.
