9.2.3 Detergent filter: cleaning
• Unscrew the screw located below the bottom tank (fig. 11, ref. 1);
• unscrew the detergent filter (fig. 11, ref. 2);
• clean the filter with running water or the detergent solution used on the machine;
• replace the filter back in its housing, making sure it is correctly positioned and retighten
the screw.
9.2.4 Squeegee blades: replacing
The squeegee blades collect the film of water and detergent from the floor and prepare the
way for perfect drying. With time, the constant rubbing leaves the edge of the blade in
contact with the floor rounded and cracked, reducing the drying efficiency and requiring it to
be replaced.
Turning or replacing the blades:
• lower the squeegee by means of the corresponding lever (fig. 6, ref. 8);
• remove the squeegee (fig. 2 ref. 6) from its mount (fig. 7 ref. 2) by completely unscrewing
the two knobs (fig. 7 ref. 3)
• remove the suction hose sleeve (fig. 7, ref. 4) from the squeegee;
• use a screwdriver to unscrew the bolt (fig. 12, ref. 3 or 6);
• remove the two blade retainers (fig. 12 ref. 2 or 7) by first pushing them towards the body
of the squeegee (fig. 12 ref. 1) then extracting them;
• remove the blade (fig. 12 ref. 4 or 5);
• reuse the same blade by reversing the edge in contact with the floor until all four edges
are worn out, or replace with a new blade, fitting it onto the screws on the body of the
squeegee (fig. 12 ref. 1);
• reposition the two blade retainers (fig. 12 ref. 2 or 7) by centring the widest part of the
slots over the fixing screws on the squeegee body (fig. 12 ref. 1), then pushing the blade
retainers inwards;
• screw up the bolt (fig. 12, ref. 3 or 6).
Replace the squeegee in its support following the instructions in paragraph 6.2.
9.2.5 Fuses: replacement (battery models)
The fuses protecting the brush and suction motors are located in the fuse holder (fig. 13, ref.
1) attached to the dirty water drum above the machine battery compartment.
To replace the fuses:
• make sure the dirty water drum is empty and empty if necessary;
• raise the dirty water drum;
• raise the fuse holder cover and remove the fuse by unscrewing the fixing screws;
• fit a new fuse and close the fuse holder cover;
• lower the dirty water drum.
Fuse table: For the complete fuse table, see the spare parts catalogue.
