IPC PW-C21 - Technical Data

16 English
EN
T echnical Data Unit
I 1508 I 1609 I 1310
Flow rate l/min
8,33 8,5 10,5
Maximum ow rate l/min
- - -
P ressure MPa
12,5 15 12
Maximum pressure MPa
15 16 13
Power kW
2,5 2,9 2,9
Maximum inlet temperature °C
60 60 60
Maximum inlet pressure MPa
1 1 1
Gun repulsive force at maximum pressure N
20,60 23,10 25,50
Pump oil type kg
0,13 SAE 15W40 0,13 SAE 15W40 0,13 SAE 15W40
Protection class -
I / I / I /
Motor insulation
Class F F F
Motor protection -
IPX5 IPX5 IPX5
Voltage V/Hz
230/50 1~ 230/50 1~ 230/50 1~
Maximum permitted electrical system impedance
Ω 0,153 0,153 0,153
Sound pressure level L
PA
(EN 60704-1)(K = 2,5 dB(A))
dB (A) 79,47 79,47 79,47
Sound power level L
WA
(EN 60704-1)(K = 2,5 dB(A))
dB (A) 93 93 93
Appliance vibration (K = 1 m/s
2
): m/s
2
2,93 2,93 2,93
Weight kg
16,8 18,4 18,4
Subject to technical modification!
Technical Data
