WARRANTY
The duration of the warranty is in accordance with the relevant
legislation in the country where the product is sold (unless
otherwise stated by the producer).
The warranty covers materials, construction and conformity
defects during the warranty period, during which time the
manufacturer will replace defective parts and repair or replace
the product if excessively worn in normal use.
The warranty does not cover components subject to normal
wear (valves, pistons, water gasket, oil gasket, springs, O-rings,
accessories such as hoses, guns, brushes, wheels, etc.).
The warranty does not cover defects caused by or resulting
from:
Technical Data
EC Declaration of conformity
- incorrect use, abuse or neglect,
- trade, professional or hire use,
- failure to service and maintain the unit as specied in the
user’s manual,
- unauthorised repairs,
- use of non-original accessories/spare parts,
- damage incurred during shipping or due to foreign objects or
substances and accidental damage,
- warehousing and stock keeping problems.
To register the warranty, the customer must provide proof of
purchase.
For service, contact the dealership where the
machine was purchased
We declare under our own sole responsibility that the product to which this declaration refers conforms to the following EU
Directives:
2006/42/EC – 2004/108/EC – 2000/14/EC
Harmonised standards applied:
EN 12100-1; EN 12100-2; EN 60335-1; EN 60335-2-79; EN55014-1; EN55014-2; EN61000-3-2; EN61000-3-3;
EN 61000-3-11-EN 60704-1
Product:
COLD WATER POWER-JET CLEANER
Model:
PW-C23P
Mod. I 1307A-M / I 1408A-M / I 1508A-M / I 1610A-M
G135-C P - I 1307A-M / G145-C P - I 1408A-M / G151-C P - I 1508A-M / G161-C P - I 1610A-M
Person authorised to create the Technical File.
IP CLEANING S.p.A. – Ucio tecnico / Technical Dep.
V.le Treviso, 63 – 30026 Portogruaro VE Italy
IP CLEANING S.p.A.
Sede Legale – Registered Oce / Sede Amministrativa – Administration
V.le Treviso, 63 – Fraz. Summaga 30026 Portogruaro (VE) ITALY
dott. Giovanni Cianci
Summaga di Portogruaro, 01/06/2012
Technical Data Unit
PW-C23P
G135-CP
Mod. I 1307A-M
PW-C23P
G145-CP
Mod. I 1408A-M
PW-C23P
G151-CP
Mod. I 1508A-M
PW-C23P
G161-CP
Mod. I 1610A-M
Output
l/min
6 6.7 7.5 9
Maximum output l/min
6.5 7.66 8.3 10
Pressure
MPa
11.5 12 14 15
Maximum pressure
MPa
13 14 15 16
Power
kW
1.9 2.3 2.5 3
T° input
°C
50 50 50 50
Maximum input pressure
MPa
1 1 1 1
Repulsive force of the gun to the maximum pressure
N
16.4 18.1 20.5 24
Motor insulation
-
Class F Class F Class F Class F
Motor protection
-
IPX5 IPX5 IPX5 IPX5
Voltage
V/Hz
230/50 230/50 230/50 230/50
Sound level K = 3 db(A) :
L
PA
(EN 60704-1)
db (A)
84.5 84.5 84.5 84.5
L
WA
(EN 60704-1)
db (A)
92 92 92 92
Unit vibrations K = 1.5M/s
2
:
m/s
2
< 2.5 3.74 1.75 1.75
Weight
kg
18 18,5 23 23,5
Subject to technical modications!
