13
the identity plate.
Carefully read the user instruc-
tions before starting the machine
for the rst time. Follow the safety
warnings.
1 MAIN COMPONENTS
We wish to thank you for choosing our machine. We are condent that the high quality of our machine will meet with
your satisfaction and appreciation and that your pressure washer will give you long-lasting service. Before starting to
use your machine, make sure to read with care this manual, which has been purposely drawn up to provide you with all
the necessary information for proper use of the machine, in compliance with basic safety requirements.
2 SAFETY PRECAUTIONS
INDEX
1 Main constructive components pag.13
2 General safety advice pag.13
3 Assembly pag.14
4 Connection of water supply pipe pag.15
5 High pressure pipe connection pag.15
6 Electrical connection of appliance pag.15
7 Appliance switch on pag.15
8 Appliance switch off pag.15
9 Accessories pag.15
10 Maintenance and repairs pag.16
11 Trouble shooting guide pag.17
1) Handle
2) Main switch
3) Detergent adjustment knob
4) Pressure gauge (optional)
5) Water inlet connection
6) Storage hooks
7) Hose drum
8) Hose reel lever
9) Detergent tank
10) Spray gun safety device
11) Trigger
12) Spray gun
13) Instructions booklet
14) Water supply rapid attachment
15) Turbo nozzle
16) High pressure pipe
Do not use the device in the vicinity of
persons, unless they are wearing the
necessary protective garments.
High pressure jets may be dangerous
if used incorrectly, the jet must never
be directed on persons, live electrical
appliances, including the appliance
itself. Never use the jet to clean your own garments
or footwear.
The high pressure of the water generated and
connection to the electricity supply constitute
particularly serious danger risks.
Before connecting the appliance to the electric
socket, check that the electric data corresponds
to that of the power supply network printed on
The appliance must be used solely by personnel
trained in its use and specically authorized to use it.
The user manual must be made available to all
users.
The hydro cleaning machine is regulated in the fac-
tory and all the safety devices contained are sealed.
Alteration of their regulation is forbidden.
Do not subject the machines to any modications
which may jeopardize personal safety.
The hydro cleaning machine is classed as a xed
appliance. Failure to respect this prescription may be
dangerous. The electrical connection must be made
by qualied technicians capable of operating in
observance of the standards in force (in compliance
with the provisions of the IEC 60364-1 standard) and
in compliance with the manufacturer’s instructions.
Incorrect connection may cause injury to people
or animals and damages to objects, for which the
manufacturer cannot be held responsible.
The electrical system to which the appliance is
connected must be realized in compliance with the
laws of the country of installation.
Whenever extension cables are used, the
relative plugs and sockets must at least
comply with protection class IPX5 (i.e. pro-
tection against water jets). Use of inappropriate or
non-compliant extension cables may incur in danger
and hazards to the device. The H.P. cleaner must
be connected to the electric supply by means of an
omnipolar switch with opening contacts of at least 3
mm. This switch must have electric features which
are consistent with the appliance.
The presence of a differential magnetothermal
switch is necessary with a sensitivity of equivalent
to 30 mA, above the power socket or the system.
The appliance is disconnected from the
electric supply only by pulling out the plug
or switching off the omnipolar switch.
Hazard levels
Hazards
Due to an imminent hazard likely to result
in severe personal injury or death.
Warning
Due to a possibly hazardous condition pre-
senting the likely occurrence of severe
personal injury or death.
Warning
Due to a possibly hazardous condition presenting
the likely occurrence of slight personal injuries
or damages to objects.
