3 ASSEMBLY
Assemble storage hook(s) (Fig. 2) to handle.
Pushrmly to ensure hook is secure.
Fit handle to hose reel using supplied screw (Fig. 3).
Before undertaking any work
on the appliance always de-
tachthe plug from the power
socket.
Connect a clean water supply pipe to
the water mains, checking to ensure that
the minimum pressure is of 1.5 bar and
maximum is of 6 bar, with a minimum ow
rate of 7 l per min.
- Connect the water supply pipe (min. diam ½”) to
the water mains (g.4)
- Unwind the pressure hose off the hose drum (Fig.
6).
- Screw the high pressure tube onto the gun
(Fig.7).
Assembly of the detergent spraying device
- Insert the nozzle and tighten the threaded locking
ring on the gun. (Fig. 8).
6 ELECTRICAL CONNECTION OF THE AP-
PLIANCE
4 CONNECTION OF THE WATER SUPPLY
PIPE
5 HIGH PRESSURE PIPE CONNECTION
The mains voltage must match the operating volta-
ge. (See identication plate)
Insert the plug into a power socket installed in
compliance with regulations.
Check the minimum section of the individual cables
using extensions.
Position the extensions so as to maintain the pro-
tection class of the equipment.
Voltage Cable Cross-section
V length m mm
2
230 up to 2 1,5
230 20 to 5 2,5
7 APPLIANCE ACTIVATION
Operate the equipment in vertical position
(g.9) only after connecting the water
supply pipe and turning on the tap.
Warning! Explosion or deagra-
tion hazards! Do not spray and/
or use inammable substances.
Check that there is sufcient air circulation in the
motor ventilation zone.
Do not cover the appliance, ensure that there is
sufcient motor ventilation.
Position the high pressure cleaner as far away as
possible from the object to be sprayed.
Do not damage the mains attachment cable by trea-
ding on it, squashing or pulling it, etc.Do not detach
the plug from the socket by pulling the connection
wire, but pull out the plug.
Make sure hands are dry before touching the plug
and the connection cable.
Hold the spraying device with both hands in order
to properly absorb the reaction force and the addi-
tional torque in the case of spraying device with an
inclined spraying pipe. Always assume a safe and
secure position.
Based on the prescriptions and provisions
set forth by the regulations currently in force,
it is mandatory that the appliance is never
operated without a potable water backow
preventer device, connected up to the potable water
supply mains. Use a suitable potable water backow
preventer device, compliant to the EN 12729 type
BA standard provisions. Water that ows through a
system backow preventer cannot be classied as
potable water.
- Screw the male connector (1 - Fig. 5) onto the at-
tachment of the water supply (2); snap the female
connector of the tube (3) on to the connector.
- Position the switch on I (ON) (Fig.10).
- Position the spray gun on the object to be
cleaned - never on people !
- Press the safety device (1-Fig.11) - the gun is
released
- Direct the nozzle downwards (Fig.9)
- Fully press down the trigger (2 Fig.11)
8 SWITCHING OFF THE MACHINE
- Position the switch on O (OFF) (Fig.10).
- Turn off water supply tap.
- Actuate spray gun until water drips from the
nozzle (machine is now de-pressurized).
- Release trigger.
- Press safety latch on spray gun. (1 Fig.11). The
spray gun is locked and cannot be actuated
accidentally.
- Unplug machine from socket outlet.
