IPC PW-C85 - Using the Cleaner; Control Panel and Starting; Stopping and Accessories

English
- 22 -
Warning
In water cleaners with the “Total Stop” system, the motor starts
and stops when the lever on the lance handle is actioned or
released.
Danger
Do not block the handle lever in the delivery position.
SIGNALS AND FAULTS DISPLAYED.
(If featured).
- Machine shutdown due to no water supply connection:
Slowash.
- Machine shutdown due to minor leaks from high pressure
circuit:Fastash.
Indicator light on steady, 200h programmed maintenance
intervalexpired.Thelightwillgoo󰀨followingmaintenanceby
the authorised service centre. (Fig. 7B).
Warning
The high pressure water jet
generates a reaction force in
thelance.Keeparmgripon
the lance handle.
4) Press the trigger on the gun
and begin washing.
USING THE ACCESSO-
RIES.
The high pressure washer
has a nozzle with a at 25°
angle jet for cleaning large
surfaces.
Warning
Aim the jet from a certain di-
stance to avoid damage cau-
sed by the high pressure.
ROTARY HEAD (optional
accessory)
USING
THE CLEANER
CONTROL PANEL
A-On/o󰀨switch.
B - Fault - Maintenance indi-
cator light. (If featured).
STARTING THE CLEANER
1) Turn on the water supply
tap(g.4A).
FIG. 9FIG. 7
FIG. 8 FIG. 10
!
!
!
!
!
!
Thehighpressurewashercanbettedwithaheadwithrotary
nozzle to clean the most stubborn dirt.
Danger:
Aim the jet from a certain distance to avoid damage caused by
the high pressure.
Do not aim the jet at people, animals or electrical sockets.
STOPPING THE CLEANER
1)Afterusingwithdetergent,ushouttheintakecircuit;place
thedetergentsuctionhose(g.9)inatankofcleanwaterand
let the pump run for 1 minute with the dosing tap turned fully
on and the lance in detergent delivery condition.
2) Stop the cleaner by turning the selector switch to pos. "0"
(g.7A).
3) Discharge the pressure from the H.P. hose by pressing the
trigger on the gun.
4) Disconnect the water cleaner from the mains electricity
supply via the omnipolar switch or by unplugging the plug from
the socket.
5)Turno󰀨thewatersupplytap(g.4A).
Warning
- If the water cleaner is left, even temporarily, turn it o󰀨 by
using the omnipolar switch or by unplugging the plug from
the socket.
- Water cleaners with the “Total Stop” device should be consi-
deredaso󰀨whentheomnipolarswitchisinthe“O”position
or the plug is unplugged from
the socket.
- When the water cleaner is not
used, close the safety device
onthehandle(g.10).
- Dry use of the water cleaner
causes serious damage to
pump gaskets.
2) Connect the water cleaner to the mains electricity supply via
the omnipolar switch or by plugging the plug into the socket.
3) Start the cleaner by turning the selector switch to pos. 1
(g.7A).
IMPORTANT!
To eliminate any impurities
or air bubbles from the wa-
ter circuit we advise starting
the cleaner for the rst time
without the lance and letting
the water run out for a few
seconds.
Impurities could block the
nozzle and cause malfun-
ction (Fig. 8).
ON
ON
ON
ON
ON
OFF
ON
OFF
A
B
A
B
