C HAPTER 10 | Class of Service
Layer 3/4 Priority Settings
– 254 –
ES-3052 Series
To show the CoS/CFI to internal PHB/drop precedence map:
1. Click Traffic, Priority, CoS to DSCP.
2. Select Show from the Action list.
3. Select an interface.
Figure 124: Showing CoS to DSCP Internal Mapping
