C HAPTER 3 | Using the Web Interface
Navigating the Web Browser Interface
– 84 –
ES-3052 Series
MAC Address 197
Static 197
Add Configures static entries in the address table 197
Show Displays static entries in the address table 197
Dynamic
Configure Aging Sets timeout for dynamically learned entries 199
Show Dynamic MAC Displays dynamic entries in the address table 200
Clear Dynamic MAC Removes any learned entries from the forwarding database and
clears the transmit and receive counts for any static or system
configured entries
201
Mirror 202
Add Mirrors traffic matching a specified source address from any port
on the switch to a target port
202
Show Shows mirror list 202
Spanning Tree 205
Loopback Detection Configures Loopback Detection parameters 208
STA Spanning Tree Algorithm
Configure Global
Configure Configures global bridge settings for STP, RSTP and MSTP 209
Show Information Displays STA values used for the bridge 215
Configure Interface
Configure Configures interface settings for STA 216
Show Information Displays interface settings for STA 220
MSTP Multiple Spanning Tree Algorithm 222
Configure Global 222
Add Configures initial VLAN and priority for an MST instance 222
Show Shows configured MST instances 222
Modify Modifies priority for an MST instance 222
Add Member Adds VLAN members for an MST instance 222
Show Member Adds or deletes VLAN members for an MST instance 222
Show Information Shows global settings for an MST instance 222
Configure Interface 226
Configure Configures interface settings for an MST instance 226
Show Information Displays interface settings for an MST instance 226
Traffic
Congestion Control
Rate Limit Sets the input and output rate limits for a port 229
Storm Control Sets the traffic storm threshold for each interface 231
Table 6: Switch Main Menu (Continued)
Menu Description Page
