MIG-160ER
5
PURPOSE AND USE
The IPOTOOLS MIG160ER is a welding machine with two welding functions. You can use it for MMA
and MIG / MAG welding. Any other use may endanger the safety of the welder or cause the device to
malfunction! Use of the device in violation of these operating instructions is not permitted! Damage to
the device resulting from improper use is not covered by the warranty statement. The machine can be
used to weld several materials, such as steel and stainless steel. The welding current is stable and
stepless adjustable. The appliance provides a beautiful weld, and the welding itself takes place quietly
and without spattering. The device is small in size, light and thus easy to transport.
TECHNICAL INFORMATION
Type MIG MAG Inverter Welding Machine MIG-160ER
Welding procedures MMA & MIG/MAG, LIFT TIG
Connection voltage 230V 1-Phase / Frequency: 50/60Hz
Housing protection IP21S
Overload display Yes
Cooling Fan
Magnetic valve Yes
MIG Duty Cycle 160A – 60% / 125A – 100%
MMA Duty Cycle 160A – 60% / 125A – 100%
Welding current MIG 40-160A / MMA: 40-160A
No-load Voltage 60 – 65 V
Welding Wire Ø MIG 100mm / Wire Ø MIG: 0,8/1,0mm
Wire feed 2 Wheels (1 with drive)
Max. welding wire diameter Ø 0,6mm / 0,8mm / 0,9mm / 1,0mm
MMA electrode diameter 1-4mm
Dimensions 360x150x350mm
Weight 8 kg
Note: The above parameters may change with future machine improvements!
