13
ASSEMBLY
ASSEMBLY
Assembling the Accessory Kit
NOTE: The wheels are not intended for over-the-road use.
1. Installing the wheels
• Slide the axle through the hole
in the center of the wheel.
Slide a washer onto the axle,
then slide the axle into the
wheel mounting hole as shown.
Insert hitch pin to secure.
•
•
2. Installing the feet
•
•
Insert bolts through the foot
bracket and holes in the
generator frame as shown.
Thread lock nuts onto bolts
and tighten one full turn past
snug.
3. CONNECTING BATTERY
• Connect the red wires to the
positive (+) terminal first, then
connect the black wire to the
negative (-) terminal. Make sure
all connections are tight.
• Cover the terminals with the
rubber covers.
