IRC POWER SLIDE CONTROL - Control Switches and Functions

12 di 18
WARNING : Put the dashboard taking care that the 2 leds are oriented directly
towards the driver’s eyes.
Sensitivity potentiometer is positioned in order to have the system OFF if counter clockwise
rotated and maximum sensitivity if completely rotated clockwise, according to numbers in
the sticker. (0 OFF, 10 max sensitivity).
In the harness with leds and potentiometer, there is the
LAUNCH CONTROL switch.
It’s ON or OFF according to pictures on the right.
When Launch Control is on, the PSC control the front wheel
height,. The front wheel will rise, more or less, 20cm and,
slowly, will go down.
Suggestion for the switch positioning: LC ON towards down
(ie. The front wheel must be down) and LC OFF upward.
In the harness with coils connectors, there is the EMERGENGY SWITCH.
L.C.
OF
L.C.
ON
