2 flashes Error on first cylinder cut.
Check harness connections on first
cylinder (Green/black-Grey wires).
Follow procedure to above 7.1.
4 flashes Error on second cylinder cut.
Check harness connections on
second cylinder (Green/red-Orange
wires). Follow procedure to above 7.1.
6 flashes Errore on anti spin hardware.
Check all harness and conenctions
are properly done and perfect. No
damaged wires must be..
Constant non-
stop flashes
No error found.
7. 1. STATUS LED (Green)
Put the dashboard taking care that the green led is oriented directly towards the driver’s
eyes.
Status led is always acting according to the following table.
MOTORCYCLE
STATUS
LED STATUS DIAGNOSYS TROUBLESHOOTING
Engien
running,
motorcycle
standing
3 quick lamps
Led shosw system is active
but on sensors imput (bike is
not running)
Pass minimum velocity
(≅10 Km/h) to activate the
system. If the 3 quick
lamps persist, follow 7.3
procedure.
Motorcycle
running
Flash every
0.5 sec
System is working properly.
If a traction loss condition
occurs and the system is
not acting, increase the
“Sensitivity” and,
eventually, check the
“Ratio”.
Motorcycle
running
Fixed green
light
System is NOT WORKING.
Switch off and on the
system. If the trouble
persists, DO NOT USE the
system and contact the
technical assistance.
Motorcycle
running
No flash System is NOT WORKING.
Switch off and on the
system. If the trouble
persists, DO NOT USE the
system and contact the
technical assistance.
Motorcycle Quick and System is cutting engine If there is no real traction
