16 di 18
running not constant
flash
power due to a traction loss
condition.
loss, reduce “Sensitivity”
and eventually, check
“Ratio” and “Pulse”.
Motorcycle
running
Constant
blinking flash,
like arrow.
The system is OFF.
Activate the system
selecting a “Sensitivity”
different from “0” moving
the knob clockwise.
7.2 Greeen light is flashing but PSC doesn’t cut.
Check that the emergency switch is T.C. ON:
If trouble persist, proceed with Emergency switch check:
Disconnect the 6 way connector.
WARNING
: Switch off engine and PSC.
With amperohmeter set on 20 KΩ or diode check, check the positions of Green/Black -
Grey wires. Acting on switch the contact should pass from open to close.
In case of 2nd connector installed (green/red – orange), repeat the check on the
following positions.
T.C.ON
