iRest A380 - Page 7

Normal Resistance
Item/Standard
Rated Voltage
Primary：
Black→Red 11～12Ω
Black→White 7～8Ω
Secondary：
Black→Black 0.4～0.5Ω
Transformer
A38-220V-24V/10A-19/4A
A38-110V-24V/10A-19/4A
AC220V
AC110V
40～50Ω
Solenoid Valve
Trigeminy
DC12V
100～150Ω
Calf rest Actuator
DDG24-242/78-H
DC24V
100～150Ω
Backrest Actuator
DDG24-428/235-H
DC24V
Remarks
AC→Alternating current DC→Direct current V→Voltage Ω→Ohm（It means coil resistance in the list）
