IRIS S55XX SERIES VIEWING HEADS
APPLICA
TION MANUAL
P
AGE 16
VIEWING HEAD
BURNER NOZZLE NO. 1
NO. 1 FLAME
ENVELOPE
NO. 2 FLAME
ENVELOPE
VIEWING HEAD
BURNER NOZZLE NO. 2
HIGH FREQUENCY
IR ZONE
LOW FREQUENCY
ZONE
(LESS THAN 36Hz)
HIGH FREQUENCY
IR ZONE
2“ NPT NIPPLE TOE
IRIS M-701-2
SWIVEL MOUNT
IRIS R-518-12
1“ NIPPLE
IRIS VIEWING HEAD
1/2“ NPT PURGE
CONNECTION
BURNER FRONT PLA
TE
BURNER NOZZLE
CENTERLINE
QUICK DISCONNECT
CABLE CONNECTION
(SUPPLIED)
FIGURE 6: SIGHTING OPPOSED FIRED BURNERS
FIGURE 7: VIEWING HEAD MOUNTING
15
17
Table of Contents
Table of Contents
2
Introduction
3
Differences between the S550B and S550
3
Signal Processor Compatibility
3
Model S550B General Description
3
Model S552B General Description
4
Model S556B General Description
4
Viewing Head Wiring
4
Viewing Head Installation
5
Figure 2: Connector Wiring
6
Sight Pipe
7
Purge Air
7
Viewing Head Sighting
7
Ir Detector
8
Uv Detector
8
Orificing
9
Default Settings for the S550B
9
Stored Viewing Head Settings
10
Assigning Settings to Channels a and B
10
Using Two Viewing Heads on the P520/P522
10
Before Making Adjustments
10
Calibrating the S550B
10
Examining the Results of Gain Settings from Calibration
11
Checking or Changing Uv Gain
11
Checking or Changing the Ir Filter
12
Checking or Changing Ir Gain
12
Manual Setup of the S550B
12
Return to Default Settings
13
Contact Information
13
Figure 3: Viewing Head Dimensions
14
Figure 4: Ir Viewing Head Location
15
Figure 6: Sighting Opposed Fired Burners
16
Figure 8: S550B Programming Flowchart
17
Figure 9: S552B Programming Flowchart
18
Figure 10: S556B Programming Flowchart
19
