IRIS S55XX SERIES VIEWING HEADS APPLICATION MANUAL
PAGE 20
SPECIFICATIONS
ELECTRICAL
Input Power: 24VDC +10%, 100mA ( powered from Signal Processor)
ENVIRONMENTAL
Sealing: Viewing Head Housing NEMA TYPE 4
Ambient Temperature: -40° F to 122° F (-40° C to 50° C)
Case Temperature: -40° F to 140° F (-40° C to 60° C)
With S580 Fiber Optics -65° F to 572° F (-54° C to 300° C)
OPTICAL
Angle of View IR 1.0°
UV 3.0°
CABLE
Signal Processor to 4 conductor, #16AWG or #18AWG.
Viewing Head One wire shielded with braided shield for flame signal
such as IRIS Part Number C328
