MINIMUM VOLUME ACCUMULATION TANK FOR BOILER TYPE IRLEH
Power output
(kW)
20 30 40 60 80
Volume (L) 1000-1500 2000-2500 2500-3000 4000-5000 5000-6000
NOTE!
The connecting piece with sockets for thermometer and temperature regulation
sensor is supplied as boiler equipment (see drawing below). This connecting piece
should be screw directly onto the outlet connecting piece of the boiler (power supply).
Thermometer and temperature regulation sensor should be placed in appropriate
sockets, as shown below.
Connecting piece with sockets
Note: do not flood the sockets with any fluids.
25. The regulation of the boilers door.
To assure the tightness of the boiler’s door and the cleanout ought periodically to oil
with the plumbago or with other machine oil the rope which seals the boiler up.
The regulation of door we execute during the work of the boiler, when the door are
shut, in the following way:
to slacken the nut 1
tighten door to the body through tighten the
nuts 2 depending on the needs
screwing tight the nut 1 to double the screw
regulatory of the hinge
