ATTACHMENTS
82
SUPERCAPRI
EN428000925100
8
WIRING DIAGRAM - 412100903000
BT1 TEMPERATURE PROBE FU1 HOT WIRE FUSE MS2 COMPRESSOR
BT2 DEFROST PROBE GD1 LED POWER SUPPLY S1 PRESSURE SWITCH
CE1 ELECTRONIC CONTROL BOARD HL1 LED CEILING LIGHT T1 TRANSFORMER
EH1 OUTSIDE PERIMETER WORKING SURFACE K1 KEYBOARD T2 TRANSFORMER
EH2 SIDE HEATING RESISTANCE REP1 TEMPERATURE REPEATER YV1 DEFROST VALVE
EH3 SIDE HEATING RESISTANCE QS1 GENERAL SWITCH YV2 4-WAY VALVE
EH4 HEATED FRONT GLASS QS2 UPPER GLASS SWITCH QS3 KVP VALVE SWITCH
EH5 HEATED SIDE GLASS FA1 FILTER B5 WATER VALVE
EH6 HEATED SIDE GLASS KA1 COMPRESSOR RELAY
EH7 HEATED UPPER GLASS KA2 TRANSFORMER RELAY
EH8 FRAME HEATING RESISTANCE KA3 PRESSURE SWITCH RELAY
EH9 FRAME HEATING RESISTANCE KA4 WATER VALVE RELAY
EV1 EVAPORATOR FAN R9 DELAY RELAY
EV2 CONDENSER FAN MS1 COMPRESSOR
