Isel ICP 4030 - Page 25

Óx
isel- Ê«>VÌÊµÕ«iÌÊÊ*
"6,/>ÃÌiÀ
(COVER switch)
COVER SchmersalSub D
Schmersal
3 4
1 2
b a
4
5
2
3
1
6
12
11
22
21
A1
A2
“1” Sub-D “1” Schmersal
“6”
Drahtbrücke
Pin b
Pin a
Pin 3
COVER-Taster
Pin 3 = “1” Sub-D
Pin 4 = “1” Schmersal
Pin a = “6” Schmersal
Pin b = Drahtbrücke
(wire bridge)
Lampe 48 Volt = Drahtbrücke
(Light 48 Volt = wire bridge)
-ÕLÊ
º£» Sub-D º£» Schmersal
-ViÀÃ>
£
x

È
-ÕLÊÊ«ÊViVÌÀ]Ê`ÊÃÜÌV (COVER) (see page 8 item ➅)
-ÕLÊÊ£x«ÊViVÌÀ]Ê*"7,ÉiÀ}iVÞvv (see page 8 items
➆)
Signal Pin Pin Signal
ON (N.O., 1. layer) 1 9 ON (N.O., 1. layer)
emergency-off (N.C., 1. layer) 2 10 lamp (in the ON-switch)
- 3 11 lamp (in the ON-switch)
- 412-
emergency-off (N.C., 1. layer) 5 13 key-switch
key-switch 6 14 ON (N.O., 2. layer)
ON (N.O., 2. layer) 7 15 emergency-off (N.C., 2. layer)
emergency-off (N.C., 2. layer) 8
