Isel ICP 4030 - Page 24

Ó{
isel Ê«>VÌÊµÕ«iÌÊ*
7.2.2 For ICP without electronic
«iÊViVÌÀÊvÀÊ8]Ê9]Ê<Ê>`Ê>ÝÃ (see page 8 items ➀ - ➃)
Signal
1 = phase 2B green
white/yellow
2 = phase 2A yellow
white/green
3 = phase 1B black
white/red
SL = phase 1A red
white/black
4 = + 24 V brake (option) black (brake)
5 = GND black (circuit board)
6 = GND brake (option) black (brake)
7 = PE shielding, frame blue (frame)
9 = reference switch yellow (circuit board)
-ÕLÊÊ«ÊViVÌÀ]Ê-/,/Ê>`Ê-/"*ÃÜÌV (see page 8 item
➄)
Signal Pin Pin Signal
- 16 -
- 2 7 start
start 3 8 stop
stop 4 9 -
- 5
