PERFORMANCE ENVIRONMENTAL
Frequency Response Characteristic Free-Field Operating Temperature Range -10…+55°
Polarization Voltage Prepolarized Storage Temperature Range -20…+70°
Nominal Sensitivity @1kHz 6mV/Pa Operating Humidity Range 0…90%r.H.
Sensitivity Temperature Drift <0.015dB/K Axial Vibration Sensitivity ~ 50dB
Microphone Polarity Non-Inverting PHYSICAL
Frequency Response calibrated 10…20.000 Hz Housing Material Stainless Steel
Frequency Response IEC61672 –2013 class 1 *1 Sealing O-ring/Polyurethane/Epoxy
Inherent Noise100-10000 Hz <30dB typ. Output Connector XLR male
Max. SPL. (3% distortion limit) > 141dBspl Dimensions Ø ¼“(7mm) x 6“(152mm)
Max. SPL. (3% distortion) typ. =143 dBspl Weight 0.3 oz (75g)
Max. SPL. (3% THD) @ 12V Phantom >140 dBspl CONFORMITY IEC 61000-6-1;
ELECTRICAL SPECIAL FUNCTIONALITY
Output Impedance < 200 Ω Voltage Surge Protection
Phantom Power 12…52Vdc EMC Noise Filter
SPECIFICATIONS
Values for 23° Celsius and 48V Phantom Power
