MT830/MT831
Installation manual
1. Meter parts
Fig. 1: Meter parts
1. LCD display
2. Meter technical data
3. IR optical interface
4. Input/output module mark
5. Legend of displaying registers on LCD
6. Meter cover sealing screw
7. Terminal cover
8. Terminal cover sealing screw
9. Communication module mark
10. RESET key blocking element
11. RESET key
12. DISPLAY key
13. Impulse diode – active and reactive energy
14. Meter cover
1
2
3
4
6
5
6
7
8
8
9
10
11
12
13
