Installation manual
Meter and fixing dimensions comply with the DIN 43857 standard.
Fig. 2: Dimensions (MT831 meter) Fig. 3: Dimensions (MT830 meter)
A compact plastic casing is made of high quality self-extinguishable materials and is resistant to water and dust (IP53).
Meter terminals
MT830 meter
Voltage terminals Auxiliary terminals
Fig.4: Terminal block – direct connected meter MT830
Sensor for terminal cover opening
Voltage link
Additional voltage terminal
