ISLABIKES Cnoc - Handlebar Set Up; Handlebar Alignment and Tightening

Cnoc 14 Small / Cnoc 14 Large / Cnoc 16 / Cnoc 20 E-mail: techsupport@islabikes.co.uk Telephone: +44 (0)1584 856 881
1. Brake levers
2. Brake pads
3. Saddle
4. Seatpost
5. Seatpost clamp
6. Saddle clamp
a. Turn handlebars anti-clockwise and align with front wheel
b. Tighten stem clamp bolt max. 7Nm
Failure to correctly tighten stem clamp bolt may result in
serious injury or death. If in doubt, please consult our technical
support team on +44 (0)1584 856 881
or email techsupport@islabikes.co.uk.
7. Stem
8. Stem bolt
9. Headset
10. Headset spacers
11. Headset adjuster bolt
12. Handlebars
13. Rim
14. Spokes
15. Tyres
16. Chain
17. Chainglider
18. Freewheel
19. Frame
20. Fork
21. Cranks
22. Pedals
Step 1 of 3
Handlebar set up
Do Not
Tighten
b. Tighten
6
5
3
1
7
8
9
10
11
4
2
13
14
15
16
17
18
19
20
21
22
12
a. Turn
