ISLABIKES Cnoc - Pedal Installation; Left and Right Pedal Installation; Adjust Saddle Height; Seatpost Adjustment Procedure

Cnoc 14 Small / Cnoc 14 Large / Cnoc 16 / Cnoc 20 E-mail: techsupport@islabikes.co.uk Telephone: +44 (0)1584 856 881
Step 2 of 3
Pedal installation
a. Left pedal – rotate pedal axle clockwise towards front of bike
b. Right pedal – rotate axle anti-clockwise towards front of bike
Tighten max. 30Nm
Please ensure you identify the left and right pedals
before installing.
Step 3 of 3
Adjust saddle height
a. Loosen seatpost-clamp
b. Move to desired height
c. Tighten clockwise max. 4Nm
Seatposts are clearly marked with minimum insertion mark.
Please do not raise saddle above this line.
Tighten
Tighten
a. Left pedal
b. Right pedal
Tighten
