DC Voltage
Range Resolution Full Scale
Accuracy (1 year
23˚C ±5˚C) Input Resistance
500mV 10V 510.00
0.02%+4
10M or >10G
5V 100V 5.1000 10M or >10G
50V 1mV 51.000 11.1M
500V 10mV 510.00 10.1M
1000V 100mV 1020.0 10M
* When the input value exceeds the full scale of the selected range, the
display will show -OL- (over load) on the display.
* The specifications are guaranteed to an input voltage of 1000V. A beeping
alarm will go off when the input voltage is higher than 1000V.
* Input protection of 1000V peak on all ranges.
DC Common Mode Rejection Ratio
>90 dB at dc, 50 or 60Hz ± 0.1% (1k unbalanced, slow rates)
DC Current
Range Resolution Full Scale
Accuracy
(1 year 23˚C ±5˚C)
Shunt
Resistance
Burden
Voltage
500A 10nA 510.00 0.05%+5 100 0.06V max
5mA 100nA 5.1000 0.05%+4 100 0.6V max
50mA 1A 51.000 0.05%+4 1 0.14V max
500mA 10A 510.00 0.10%+4 1 1.4V max
5 A 100A 5.1000 0.25%+5 10m 0.5V max
10 A 1mA 12.000 0.25%+5 10m 0.8V max
* 500A~500mA range has a 3.6V voltage limit protection and 0.5A fuse
protection. And 10A range has a 12A fuse protection.
* When the input value exceeds the full scale of the selected range, the
display will show -OL- (over load) on the display.
* The specifications are guaranteed to an input of 10A. A beeping alarm will
go off when the input value is higher than 10A.
