2.1 Inserting/Exchanging rotating gobos
( For IR-7S/IR-7B/ IR-5C only ! )
DANGER!
Install the gobos with the device switched off only.
Unplug from mains before!
Open the cover by loosening the fastening screw at the sides of the cover.
If you wish to use other forms and patterns as the standard-gobos, or if the gobos are to be
exchanged, remove the fixation ring with an appropriate tool. Remove the gobo and insert the
new gobo. Press the fixation-ring together and insert it in the front of the gobo.
CAUTION!
Never unscrew the screws of the rotating gobo as the ball bearing
will otherwise be opened!
IS-6S/IS-6B/IS-4 ( IS-4 is a 4 channel gobo rotator )
