What does the 'ALARM WARNING NEXT SERVICE' mean on the IST ATEX HR 600 Distilling equipment?
The 'ALARM WARNING NEXT SERVICE' on your IST Distilling equipment indicates at the end of every cycle that the expiry date for maintenance is near. Press the Stop button to switch the alarm off.
What to do if my IST ATEX HR 600 displays 'TEMP. CONTR. ALARM'?
If the IST Distilling equipment displays 'TEMP. CONTR. ALARM', it indicates a malfunction of the contactors that control the heating element, or the heating element safety thermostat has intervened. To resolve this, functioning blocks Contact assistance Take away protection car- ter (pict.1) and unscrew the heating element box (11). Unscrew the cap (A) and press button (B) to reset.
What to do if the IST ATEX HR 600 displays 'ALARM MAX. LOADING LEVEL'?
If the IST Distilling equipment displays 'ALARM MAX. LOADING LEVEL', it means that the max. level control did not function in the set safety time, blocking the reclaimer's function. This can happen if the loading pump does not function, or if it functions at a lower speed than normal. Check the flow regulator on the compressed air inlet.
What to do if my IST ATEX HR 600 displays 'WATCH DOG ALARM'?
If the IST Distilling equipment displays 'WATCH DOG ALARM', it means that the reclaimer is blocked, but the microprocessor is not malfunctioning. Wait for some seconds then turn the main switch (1) to the off position (0) and then to the on position (1). Try again various times and if the problem persists contact the servicing.
What to do if my IST Distilling equipment displays 'ALARM OUTPUTTING SOLVENT TEMPERATURE T3'?
If the IST Distilling equipment displays 'ALARM OUTPUTTING SOLVENT TEMPERATURE T3', it means that during the working cycle the solvent temperature was higher than the set temperature T3. This can be caused by: - The electro-fans not functioning correctly. - The room temperature being the same as the T3 set temperature. - The condenser being dirty and/or dusty. - The water cooling circuit being blocked or not functioning (only for water cooling).
Why is my IST ATEX HR 600 Distilling equipment displaying 'OIL TEMPERATURE ALARM FOR TANK OPENING'?
The 'OIL TEMPERATURE ALARM FOR TANK OPENING' on your IST Distilling equipment indicates that the oil temperature is too high to open the tank and to carry out any other maintenance. Wait for the temperature to drop. It is possible to open the residuals discharge valve.
What to do if vacuum does not increase in my IST ATEX HR 600 Distilling equipment?
If vacuum does not increase in your IST Distilling equipment: - Verify the correct tank position. - Check the complete closing of the pneumatic valves. - In case of pneumatic vacuum, check the pump and check the chemical compatibility of the solvent with the seals. - In case of electric vacuum or liquid ring vacuum, check the rotation sense of the motor.
Why is solvent coming out from the vent valve of my IST Distilling equipment?
If solvent is coming out from the vent valve of your IST Distilling equipment: - The vapours collecting pipe is obstructed and does not allow the passage toward the condenser. - The T1 oil temperature set is too high.
What to check if my IST ATEX HR 600 is less productive?
If your IST Distilling equipment has become less productive: - The vapours collecting pipe inside the tank is obstructed and blocks the passage. Check the conditions of this pipe. - The distillation tank is too dirty and the residue left on the walls does not allow the necessary thermic exchange. - If the machine is equipped with vacuum, check the vacuum level reached and check for possible leaks. - Solvent mix has been modified. - Functioning parameters have been modified. - Heating elements are not working properly. Check the electric current (in Amps) during the heating phase. - The ordinary maintenance oil change has not been carried out, causing carbon residuals inside the heating circuit that makes the thermic exchange worse.
How to troubleshoot if my IST Distilling equipment's display does not turn on?
If the display of your IST Distilling equipment does not turn on and the reclaimer does not work: - Verify there is input power. - Check that the eventual main switch of the electric installation is connected. - Open the control panel and verify the fuses conductivity.
General| Type | Distilling equipment |
|---|---|
| Capacity | 600 liters |
| Material | Stainless steel |
| Heating System | Electric |
| Cooling System | Water-cooled |
| Model | ATEX HR 600 |
Emphasizes thorough reading of the manual for safe operation and maintenance.
Guide for operators and technicians on manual usage for safe operation.
Information on hazardous reactions with specific solvents and precautions.
Overview of the Solvent Reclaimer's main components and their functions.
Key specifications including capacity, power, operating temperatures, and standards.
Detailed explanation of the reclaimer's design, function, and intended solvent types.
Defines improper usage and the manufacturer's disclaimer for damages.
Guidance on professional assembly and positioning of optional tanks.
Requirements for the installation environment, including ventilation and ATEX zoning.
Safety guidelines and requirements for making electrical connections.
Overview of the external and internal control panels and their components.
Steps for programming the reclaiming cycle, including default settings.
Navigation through the control panel menus and display information.
Procedure to access and modify parameters using a password.
Options for selecting different reclaiming cycle types (e.g., Automatic, Timed).
Detailed guide on setting temperatures (T1, T2, T3) and cycle times.
Options for managing residual discharge after cycles.
Safety precautions required before performing any maintenance.
General maintenance recommendations and schedule.
Step-by-step procedure for replacing the diathermic oil.
List of alarm messages and their meanings with reset instructions.
Troubleshooting guide for common issues and their resolutions.
