Roughing in
I2000M
The I2000M master unit uses the I2000H housing unit for installation. The I2000H housing unit will
install between the wall studs before the drywall is installed. The install dimensions of the I2000H
housing unit is 14½ X 5¾ X 3¼. Make sure the electrical box is on the bottom as you install the I2000H
housing unit. Typically the I2000H will install 50inches off the floor. Screw in the I2000H housing unit
into the studs making sure the I2000H housing unit is level. Install the electrical outlet box into the slot
on the master and hook up the dedicated 110V line to the wires provided on the electrical outlet box.
