21
Maintenance
MainTenance
USE WITH BAG
Change the bag when the one in place is full.
Frequency will depend on the use of the unit.
1. To access the bag, unlatch the two
clips and remove the dust receptacle
(gure 13).
2. Remove the used bag and seal bag
opening (adhesive seal provided on each
bag). Discard used bag.
3. Install the new bag, ensuring the tabs on
the bag adaptor are aligned with the slots
in the bag collar (gure 14).
4. Ensure adequate sealing by inserting bag
as far as the retention ring.(gure 15-A).
Rotate bag 20° (gure 15 - B) to ensure
tabs on bag adaptor are no longer aligned
with the slots in the bag collar..
5. Replace dust receptacle and seal by
latching both clips.
Use only genuine ITL replacement bags.
Failure to do so could void the warranty
on your vacuum unit.
Parts number :
Models S5, S7, S8 – TDSAC23N
gure 14
gure 13
retention
ring
gure 15
A
B
tabs on bag
adaptator
