IST M40 - Schematic; Schematic - Other Models

7
scheMaTic
1. Circuit Breaker
2. Low Voltage Connector (M70 & 80 with LED)
3. Serial Number
4. Air Intake
5. Air Exhaust
6. Mufer (optional)
4
3
2
1
5
min. 30 cm (12")
min. 30 cm (12")
Recommended 40 cm (16")
min. 30 cm (12")
min. 30 cm (12")
min. 30 cm (12")
With mufer turned down
6
Model may differ from the illustration.
