Note: Drawing is an example only, not all types of L-brackets are shown
“L-type” Bracket Assembly
Familiarize yourself with the parts of the
mounting system.
(1) Mounting Bracket
(2) Pinch Plate
(3) Pinch Plate Screws
(4) Ribbon Cable
These are the general mounting instructions
for IST Touch Systems that use an “L-type”
bracket as shown here.
If you have “Spring-type” bracket, as
shown here, please refer to the Spring
bracket assembly instructions on page
3.
To Next Page
