Istore 180L - 2.2 Dimensions 180 L

iStore - Installation Manual - Aug 2023
8
Specifications
2.2 Dimensions 180L
Dimensions
Height (mm) 1957
Diameter (mm) 540
Height to water inlet (mm) 60
Height to water outlet (mm) 1240
Hot water condensation (mm)
Height to PTR Valve (mm)
Height to Anode 1140
Net weight (Kg) 93
1956
1240
1240
1140
540
60
Unit: mm
HW outlet
HW condensation
PTR Valve
Anode
Cold water inlet
Overall height
Overall width
180L iStore
Top View 583
