4-27
CONTROLS AND INSTRUMENTS
Voltmeter
The voltmeter shows the current status of charge of the battery.
Press the MID select knob to select the voltmeter.
The screen automatically changes to an abnormal voltage display (red letters on black
background), even if the voltmeter is not selected whenever the battery voltage drops
to the "L" level or rises to the "H" level. If a voltmeter sign appears with red, have the
vehicle checked and serviced at the nearest Isuzu Dealer as soon as possible.
Message Display indication Color Descriptions
Voltmeter
Green
Indicates the current status of
charge of the battery.
Red
This means the battery voltage is
too low.
Red
This means the battery voltage is
too high.
NOTE
During or immediately after engine start, abnormal "L" voltage (red letters on
black background) may appear on the MID. If the warning disappears after the
engine has started, there is no problem with the battery voltage.
•
