 iSYSTEM, March 2017 17/66
Good signal integrity at lower frequency with large
“Data eyes”
Trace Line Calibration window – scan has been
performed and applied.
X
invalid area
.
valid area
R
recommended
o
currently used
Higher frequency: Valid “Data eyes” shown on
upper data signal and how the clock (lower) must be
delayed.
