Auxiliary supply PFC5 PFC7 PFC8 PFC12
Rated voltage Ue 380… 415VAC (other values on request)
Operating limit -15%… +10% Ue
Rated frequency 50 o 60Hz ±1% (self configurable)
Maximum consumption 6.2VA 5VA
Maximum dissipation 2.7W
3W
Maximum power dissipated by output contacts 0.5W with 5A
Immunity time for micro-breaking
30ms
No-voltage release
8ms
Current input
Rated current Ie 5A (1A on request)
Operating limit 0.125… 6A
Constant overload +20%
Type of measurement True RMS
Short time withstand current 10Ie for 1s
Dynamic limit 20Ie for 10ms
Input power 0.65W
Output relay PFC5 PFC7 PFC8 PFC12
Number of outputs
(1 output contact is galvanically isolated)
5 7 8 12
Type of output 4+1 N/O 6+1 N/O
7 N/O +
1 C/O
11 N/O +
1 C/O
Maximum current at contact common 12A
Rated capacity Ith 5A
Rated operating voltage 250VAC
Maximum switching voltage 400VAC
Designation according to
IEC/EN 60947-5-1 AC-DC
C/250, B/400
Electrical life at 0.33A, 250VAC
and AC11 load conditions
5x10
6
ops
Electrical life at 2A, 250VAC
and AC11 load conditions
4x10
5
ops
Electrical life at 2A, 400VAC
and AC11 load conditions
2x10
5
ops
Control range
Power factor setting 0.80ind… 0.80cap
Reconnection time of the same step 5… 240s
Sensitivity 5… 600s/step
Connections
Type of terminal Removable / Plug-in
Cable cross section (min-max) 0.2÷2.5mm² (24÷12 AWG)
Tightening torque 0.8 Nm (7LBin)
GB
1.22 TECHNICAL CHARACTERISTICS
