PROBLEM CAUSE CORRECTION
Fasteners jam in tool or 1. Joint guide is worn 1. Replace joint guide
magazine 2. Fasteners are the wrong size or damaged 2. Use only the recommended and undamaged
fasteners
3. Magazine or front plate screws are loose 3. Tighten all screws
4. Blade in piston assembly is damaged 4. Replace piston assembly
Tool will not drive fasteners down 1. Worn blade in piston assembly 1. Replace piston assembly
tight 2. Lack of power 2. Adjust regulator to adequate air pressure
3. Slow cycling and loss of power 3. Check cylinder cap spring for broken coils or
reduced length or if exhaust port of cylinder
cap is restricted
PARTS LIST
TROUBLESHOOTING
Please refer to the schematic drawing on page 17
ITEM DESCRITPION ITEM DESCRITPION
1 Screw 41 Lock washer
2 Bushing 42 Pin
3 Exhaust cover 43 Trigger
4 Washer 44 Lock Washer
5 Screw 45 Screw
6 Cylinder cap 46 Plate
7 Gasket 47 Front plate
8 Seal 48 Bar guide
9 Spring 49 Pin
10 O-ring 15.7 x 2 50 Pin
11 O-ring 38.3 x 3 51 Pin
12 Valve 52 Guide
13 O-ring 36.3 x 3.5 53 Rail
14 Stopper washer 54 Pin
15 O-ring 50.5 x 2.5 55 Movable magazine nut
16 Collar 56 Screw
17 O-ring 30.3 x 3 57 Lock
18 Piston assembly 58 Pin
19 O-ring 40.2 x 2.3 59 Locking Washer
20 Cylinder 60 Feeder
21 Bumper 61 Spring
62 Spring Retainer
23 Body 63 Cover
24 Joint guide 64 Stopped Plate
25 Safety guide 65 Fixed Magazine Unit
26 Spring 66 Screw
27 Safety bracket A 67 Support
28 Safety bracket assembly 68 Nut
29 Safety bracket B 69 Soft grip sleeve
30 Pin 70 End Cap
31 Seal 71 Air Plug
32 Trigger valve head
33 Spring
34 O-ring 5.5 x 1.5
35 Trigger valve stem
36 O-ring 15 x 1.9
37 Trigger valve guide
38 Trigger spring
39 Pin
40 Screw
