NAILER/STAPLER PARTS LIST
BRAD NAILER TROUBLESHOOTING
STOP using the tool immediately if any of the following problems occur. Serious
personal injury could occur. Any repairs or replacements must be done by a
qualied person or an authorized service centre only.
CAUTION: Disconnect the tool from air supply before performing any service pro-
cedure. When inserting new or re-installing O-rings, make sure they are clean
and lubricated with an O-ring lubricant.
ITEM DESCRIPTION
1 Screw
2 Bushing
3 Exhaust cover
4 Washer
5 Screw
6 Spring washer
7 Cylinder cap
8 Gasket
9 Cylinder extension
10 Seal
11 Spring
12 O-ring 15.7 x 2
13 O-ring 38.3 x 3
14 Valve
15 O-ring 36.3 x 3.5
16 Stopper washer
17 O-ring 50.5 x 2.5
18 Collar
19 O-ring 30.3 x 3
20 Piston assembly
21 O-ring 40.2 x 2.3
22 O-ring 35.6 x 1.8
23 Cylinder
24 Bumper
25 Body
26 Joint guide
27 Safety guide
28 Spring
29 Safety bracket
30 Safety bracket assembly
31 Pin
32 Seal
33 Trigger valve head
34 Spring
35 O-ring 5.5 x 1.5
36 Trigger valve stem
37 O-ring 15 x 1.9
38 Trigger valve guide
39 Trigger spring
40 Trigger
41 Pin
ITEM DESCRIPTION
42 Lock washer
43 Pin
44 Plate
45 Screw
46 Latch assembly
47 Pin
48 Front plate
49 Bar guide
50 Pin
51 Screw
52 Guide body
53 Rail A
54 Fixed magazine unit
55 Stopper
56 Spring washer
57 Screw
58 Movable magazine nut
59 Bushing A
60 Stopper plate
61 Screw
62 Screw
63 Lock
64 Torsion spring
65 Lock washer
66 Pin
67 Nut
68 Bushing B
69 Screw
70 Pin
71 Feeder shoe
72 Spring
73 Rail B
74 Screw
75 Support
76 Nut
77 Screw
78 Belt hook
79 Soft grip sleeve
80 End cap
81 Air plug
PLEASE REFER TO SCHEMATIC DRAWING PAGE 25
