1. FANNER
2. CH1~CH10
LED level meter
3. MONITOR
Volume control
4. CHANNEL
CH Selecting switch
4. NOMENCLATURE AND FUNCTIONS
31 6
4.1 FRONT PANEL
4 52
6
ON
POWER
OFF
MONITOR CHANNEL
CH1 CH2
CH3
CH4 CH5 CH6 CH7 CH8 CH9 CH10
+24dB
+18dB
+12dB
+6dB
0dB
6. POWER
Power indicator
5. POWER SWITCH
On top of the opening Power
Press the end, power shut down
