6. APPLICATIONS

REAR PANEL CONNECTIONS

SPEAKER SELECTORS

COM

INPUT A

INPUT B

ALARM A

ALARM B

+ CH 1 - + CH 3 - + CH 4 - + CH 5 - + CH 6 - + CH 7 - + CH 8 - + CH 9 - + C H 10 -+ CH 2 -

+ 1 - + 2 - + 3 - + 4 - + 5 - + 6 - + 7 - + 8 - + 9 - + 10 -

ALARM IN

+ 1 - + 2 - + 3 - + 4 - + 5 - + 6 - + 7 - + 8 - + 9 - + 10 -

ALARM OUT

~220-240V 50/60Hz

T1AL250V

SPEAKER

CH 1 CH 2

CH 3

CH 4 CH 5 CH 6 CH 7 CH 8 CH 9 CH 10
